Dodge Ram 5.9L Cummins HE351CW 62mm turbo front view

HE351CW 62mm 4043600 5143256AA Turbocharger for 2004.5-2007 Dodge Ram 5.9L Cummins

This HE351CW configuration features a 62mm compressor inducer with 86mm exducer for the 2004.5-2007 Dodge Ram 2500/3500 with the 5.9L Cummins ISB 24-valve diesel. It is a drop-in alternative to the stock HE351CW with a slightly larger compressor wheel for more airflow on tuned trucks — same fixed-geometry design, internal wastegate, T3 flange, and bolt-on fitment. Holset interchange 4043600, 4036835, 4089797; Mopar 5143256AA. Built new, dynamically balanced, ships with gaskets. We supply diesel shops and distributors.

Turbo Model

HE351CW (62/86mm compressor, fixed geometry, internal wastegate, T3 flange)

OEM / Interchange Numbers

4043600, 4036835, 4036836, 4037001, 4037002, 4089797, 4089673, 5143256AA

Application

2004.5-2007 Dodge Ram 2500/3500 5.9L Cummins ISB 24V

Service & Support

  • 1-Year Unlimited-Mileage Warranty
  • US Stock, Fast Dispatch
  • Bulk Orders Welcome
  • White-Label Support
  • Fully Certified
Get a Quick Quote

Your Source for Quality Diesel Engine Parts

  • US stock fast dispatch icon
  • 100% brand new parts icon
  • 1-year warranty icon
  • Wholesale pricing icon
  • White-label support icon
  • Fully certified quality icon

FAQ

The 2004-5-2007 Dodge Ram 2500/3500 with the 5-9L Cummins ISB 24-valve diesel. Direct drop-in on the stock T3 flange.

The compressor inducer is 62mm instead of the stock 60mm, flowing slightly more air for tuned trucks. Same housing, wastegate, and fitment as the stock HE351CW.

Brand new, dynamically balanced, ships with gaskets. No core charge. One-year unlimited-mileage warranty.

Yes. US stock, volume pricing for diesel shops and distributors.

It replaces 4043600, 4036835, 4036836, 4037001, 4037002, 4089797, 4089673, and 5143256AA. Match by the number on the turbo nameplate before ordering.

HE351CW 62mm: More Airflow for the 5.9L Cummins

The stock HE351CW runs a 60mm compressor inducer. This configuration steps up to 62mm — a mild airflow upgrade that supports tuned trucks (programmer, injectors, exhaust) while keeping stock-like spool and full drop-in fitment. No fabrication, no VGT, no electronics.

HE351CW compressor options

ConfigurationCompressorBest for
Stock HE351CW60/86mmStock replacement
This page (#8)62/86mmMild tune, towing headroom
Configuration #1060/86mmStock-spec alternative

Cross Reference Numbers

This turbocharger replaces the following OE and interchange numbers:

  • 4043600
  • 4036835
  • 4036836
  • 4037001
  • 4037002
  • 4089797
  • 4089673
  • 5143256AA

Related configuration: HE351CW 60/86mm stock configuration.

Installation and Care

  • Find out why the old turbo failed before installing the new one. Oil starvation or contaminated oil will destroy the replacement the same way.
  • Change the engine oil and filter. Flush or replace the oil feed line.
  • Direct bolt-on T3 flange. Ships with gaskets.
  • Flush oil feed line. Prime turbo before startup.
  • Idle 3-5 minutes before loading.

See our quality process for details.
